AYA No. 1
- Category
- Shotgun
- Barrel
- 711 mm
- Weight, empty
- 3.10 kg
- Introduced
- 1955
About
What it is, and why it matters
The AYA No. 1 is a Spanish best-quality hammerless sidelock side-by-side double-barrelled shotgun, the flagship game gun of Aguirre y Aranzabal of Eibar. It uses an assisted-opening, square-bar action with hand-detachable Holland & Holland-pattern sidelocks built on a forged steel body, double locking, intercepting safety sears and gold-lined cocking indicators. Chopper-lump barrels of chrome-nickel steel with fixed chokes are paired with a Southgate over-centre automatic ejector system and double triggers. Chambered most commonly in 12 gauge for 2¾-inch cartridges and also offered in 16 and 20 bore, the No. 1 is the deluxe sibling of the No. 2, carrying finer rose-and-scroll engraving and upgraded walnut.
Aguirre y Aranzabal was founded in 1917 in Eibar by Nicolas Aranzabal and the Aguirre brothers. The No. 1 became the house's pre-eminent best-quality sidelock, the gun against which AYA's reputation for affordable Holland & Holland-style craftsmanship was measured.
The No. 1 sits above the No. 2 in the AYA range, sharing the same Holland & Holland-derived mechanism but with hand-detachable locks, assisted opening, finer engraving and select wood. Standard barrel length is 28 inches with 27-30 inch options; chambers are 2¾ inch (70mm) and chokes are fixed (commonly quarter and half). Typical 12-bore weight is around 6½-6¾ lb. Some markets list the imported No. 1 as discontinued circa 1985, though AYA continues to offer the model.
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- Aguirre y Aranzabal S.A.L.
- Category
- Shotgun
- Country
- Spain
- Status
- In production
- Produced
- 1955
- Variant of
- Deluxe sidelock
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 711 mm
- Overall length
- 1143 mm
- Weight, empty
- 3.10 kg
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Break action
- Firing mechanism
- Hammer fired
- Trigger
- Double trigger
- Capacity
- 2
- Magazine
- Internal
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Steel
- Barrel
- Steel
- Stock
- Walnut
- Finish
- Color case hardened
BallisticsFrom the service cartridge, not a handload.
- Muzzle velocity
- 400 m/s
- Effective range
- 40 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
No load solved for this record yetThe flight path is computed from a cartridge and a bullet. This record has no ammunition filed against its chambering, so there is nothing to solve.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
Sidelock
Hand detachable locks
Side by side barrels- Assisted opening
Double trigger
Automatic ejectors
Southgate ejectors
Chopper lump barrels
Chrome nickel steel barrels
Rose and scroll engraving
Straight hand stock
Fixed chokes
2 75 inch chamber
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 622 12 Gauge shotguns | 3.10 kg | 3.29 kg | Lighter than about 80% |
| Overall lengthAmong 570 12 Gauge shotguns | 1143 mm | 1150 mm | Shorter than about 60% |
| Barrel lengthAmong 650 12 Gauge shotguns | 711 mm | 711 mm | Longer than about 60% |
| Magazine capacityAmong 647 12 Gauge shotguns | 2 | 3 | Holds fewer rounds than about 70% |
Answers
Questions about the AYA No. 1
How much does the AYA No. 1 weigh?
The AYA No. 1 weighs 3.10 kg (6.83 lb) empty.
What caliber is the AYA No. 1?
The AYA No. 1 is chambered in 12 Gauge.
How many rounds does the AYA No. 1 hold?
The AYA No. 1 holds 2 rounds, fed from an internal magazine.
How long is the AYA No. 1?
The AYA No. 1 is 1143 mm (45.0 in) long overall, with a 711 mm (28.0 in) barrel.
Who makes the AYA No. 1?
The AYA No. 1 is made by Aguirre y Aranzabal S.A.L. (Spain). It was designed by Aguirre y Aranzabal.
When was the AYA No. 1 introduced?
The AYA No. 1 was introduced in 1955.
How does the AYA No. 1 operate?
The AYA No. 1 uses a break action, and its firing mechanism is hammer fired.
