Browning A5
- Category
- Shotgun
- Barrel
- 711 mm
- Weight, empty
- 3.09 kg
- Introduced
- 2012
About
What it is, and why it matters
The Browning A5 is a recoil-operated semi-automatic shotgun reintroduced by the Browning Arms Company in 2012 as a modern successor to the legendary Browning Auto-5, which was the first mass-produced semi-automatic shotgun when it debuted in 1902. The modern A5 retains the iconic humpback receiver profile of its predecessor but is an entirely new design featuring the Kinematic Drive system -- a short-recoil operated action that harnesses kinetic energy to cycle the bolt. Unlike the original Auto-5's long recoil operation, the Kinematic Drive uses a short-recoil principle more similar to inertia-driven systems, resulting in faster lock time and reliable cycling with a wide range of ammunition from light 1-ounce field loads to heavy magnum turkey and waterfowl loads without adjustment. The A5 features an aluminum alloy receiver, chrome-plated chamber and bore, back-bored Vector Pro barrel with Invector-DS choke tubes, and Browning's Speed Load Plus feeding system. Available in 12, 16, and 20 gauge with 3-inch or 3.5-inch chambers depending on the model, the A5 is primarily a sporting and hunting shotgun. It was the first autoloading shotgun to carry a 100,000-round or five-year reliability guarantee.
The modern A5 pays homage to John Browning's original Auto-5, the first mass-produced semi-automatic shotgun when it debuted in 1902. The iconic 'humpback' receiver profile is preserved, but the Kinematic Drive system is an entirely new design. It was the first autoloading shotgun to carry a 100,000-round or five-year reliability guarantee.
The modern Browning A5 (2012) should not be confused with the original Browning Auto-5 (1902-1998), which used a long-recoil operating system designed by John Moses Browning. The original Auto-5 was manufactured by Fabrique Nationale (FN) in Belgium from 1902 and later by Miroku in Japan from 1975 until 1998. The modern A5 is manufactured by Miroku in Japan. The Kinematic Drive system is distinct from Benelli's inertia-driven system, though both operate on similar short-recoil principles. The back-bored barrel (0.742 inches vs. nominal 0.729 inches) reduces friction and improves pattern consistency. The Invector-DS (Double Seal) choke tubes feature a longer taper and bronze seals to eliminate gas blow-by and fouling at the choke-barrel junction. The Speed Load Plus system allows quick loading of a single shell directly into the chamber by dropping it onto the carrier and pressing the bolt release. The Sweet Sixteen variant revives the beloved 16-gauge configuration from the original Auto-5 line.
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- Browning Arms Company
- Category
- Shotgun
- Country
- United States
- Status
- In production
- Produced
- 2012
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 711 mm
- Overall length
- 1261 mm
- Weight, empty
- 3.09 kg
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Recoil operated
- Firing mechanism
- Hammer fired
- Trigger
- Single stage
- Trigger pull
- 30.0 N
- Capacity
- 4
- Magazine
- Tubular
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Aluminum
- Barrel
- Steel
- Stock
- Wood
- Finish
- Blued
BallisticsFrom the service cartridge, not a handload.
- Effective range
- 45 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
No load solved for this record yetThe flight path is computed from a cartridge and a bullet. This record has no ammunition filed against its chambering, so there is nothing to solve.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
- Kinematic drive system
Humpback receiver profile
Invector ds choke system
Back bored barrel
Vector pro forcing cone
Chrome chamber and bore- Speed load plus system
Inflex ii recoil pad- Turnkey magazine plug
Fiber optic front sight
Ivory mid bead sight
3 inch chamber
Nickel teflon internal coating
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 622 12 Gauge shotguns | 3.09 kg | 3.29 kg | Lighter than about 80% |
| Overall lengthAmong 570 12 Gauge shotguns | 1261 mm | 1150 mm | Longer than about 90% |
| Barrel lengthAmong 650 12 Gauge shotguns | 711 mm | 711 mm | Longer than about 60% |
| Magazine capacityAmong 647 12 Gauge shotguns | 4 | 3 | Holds more rounds than about 60% |
Answers
Questions about the Browning A5
How much does the Browning A5 weigh?
The Browning A5 weighs 3.09 kg (6.81 lb) empty.
What caliber is the Browning A5?
The Browning A5 is chambered in 12 Gauge.
How many rounds does the Browning A5 hold?
The Browning A5 holds 4 rounds, fed from a tubular magazine.
How long is the Browning A5?
The Browning A5 is 1261 mm (49.6 in) long overall, with a 711 mm (28.0 in) barrel.
Who makes the Browning A5?
The Browning A5 is made by Browning Arms Company (United States).
When was the Browning A5 introduced?
The Browning A5 was introduced in 2012.
How does the Browning A5 operate?
The Browning A5 uses a recoil operated action, and its firing mechanism is hammer fired.
