Karabiner 98a
- Category
- Carbine
- Barrel
- 590 mm
- Weight, empty
- 3.42 kg
- Introduced
- 1908
About
What it is, and why it matters
The Karabiner 98a (Kar98a, also catalogued as the Karabiner 98AZ) is a German bolt-action carbine derived from the Gewehr 98, chambered in 7.92x57mm Mauser and fed from a five-round internal magazine via stripper clips. Adopted by the Imperial German Army, it shortened and lightened the long Gewehr 98 for cavalry, artillery, signal and assault troops, featuring a turned-down bolt handle and a stacking rod with bayonet lug. It is the WWI-era predecessor of the later Karabiner 98k.
Issued to cavalry, artillery and the Stormtroopers of the late-war German offensives, the handier Kar98a foreshadowed the universal short-rifle concept that Mauser would finalize two decades later as the Karabiner 98k.
Confusion exists in collector literature between this WWI carbine and the WWII Karabiner 98k; the 'AZ' suffix referenced the Aufpflanz- und Zusammensetzvorrichtung (bayonet lug and stacking rod) that distinguished it from earlier short rifles. The Kar98a is noticeably longer than a true carbine, sitting between a full rifle and the later short rifle in length.
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- Mauser
- Category
- Carbine
- Country
- Germany
- Status
- Out of production
- Produced
- 1908 to 1935
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 590 mm
- Overall length
- 1090 mm
- Weight, empty
- 3.42 kg
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Bolt action
- Firing mechanism
- Rotating bolt
- Trigger
- Single stage
- Capacity
- 5
- Magazine
- Internal
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Steel
- Barrel
- Steel
- Stock
- Wood
- Finish
- Blued
BallisticsFrom the service cartridge, not a handload.
- Muzzle velocity
- 850 m/s
- Effective range
- 500 m
- Maximum range
- 3700 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
No load solved for this record yetThe flight path is computed from a cartridge and a bullet. This record has no ammunition filed against its chambering, so there is nothing to solve.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
Controlled round feed
Stripper clip loading
Turned down bolt handle
Tangent leaf sight
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 409 carbines | 3.42 kg | 3.00 kg | Heavier than about 80% |
| Overall lengthAmong 407 carbines | 1090 mm | 895 mm | Longer than about 90% |
| Barrel lengthAmong 423 carbines | 590 mm | 406 mm | Longer than about 90% |
| Magazine capacityAmong 423 carbines | 5 | 21 | Holds fewer rounds than about 80% |
Answers
Questions about the Karabiner 98a
How much does the Karabiner 98a weigh?
The Karabiner 98a weighs 3.42 kg (7.54 lb) empty.
What caliber is the Karabiner 98a?
The Karabiner 98a is chambered in 7.92x57mm Mauser.
How many rounds does the Karabiner 98a hold?
The Karabiner 98a holds 5 rounds, fed from an internal magazine.
How long is the Karabiner 98a?
The Karabiner 98a is 1090 mm (42.9 in) long overall, with a 590 mm (23.2 in) barrel.
Who makes the Karabiner 98a?
The Karabiner 98a is made by Mauser (Germany). It was designed by Paul Mauser.
When was the Karabiner 98a introduced?
The Karabiner 98a was introduced in 1908 and discontinued in 1935.
How does the Karabiner 98a operate?
The Karabiner 98a uses a bolt action, and its firing mechanism is rotating bolt.
