FN Reflex
- Category
- Pistol
- Barrel
- 84 mm
- Weight, empty
- 522 g
- Introduced
- 2023
About
What it is, and why it matters
The FN Reflex is a micro-compact, 9x19mm Parabellum concealed-carry pistol introduced by FN America in 2023. It distinguishes itself from the striker-fired crowd that dominates the micro-9 class by using an internal hammer-fired, single-action-only (SAO) ignition system. FN's stated rationale is twofold: the internal-hammer SAO design yields a cleaner, lighter trigger pull (rated 4.5 to 5.5 pounds) while also producing a slide that is markedly easier to rack than typical striker guns, an important benefit for recoil- and grip-strength-sensitive shooters. The pistol measures 6.2 inches overall with a 3.3-inch cold-hammer-forged barrel featuring a recessed target crown and polished chamber and feed ramp, stands 4.27 inches tall, and is just one inch wide at the slide. Empty weight is 18.4 ounces (about 522g). It ships with an 11-round flush magazine and a 15-round extended magazine, and a 10-round option is offered for restricted markets. Standard sights are a high-visibility three-dot setup with a tritium front insert ringed in orange. The Reflex incorporates multiple redundant safeties. An optics-ready variant, the Reflex MRD, adds a milled slide for direct-mount micro red dot optics.
FN bucked the micro-9 orthodoxy with the Reflex: while nearly every competing pocket 9mm is striker-fired, the Reflex hides an internal hammer for a single-action-only trigger, a choice FN says yields both a crisper trigger break and a slide light enough for weaker hands to rack with ease.
MSRP at launch was approximately $614. The defining feature is the internal hammer-fired single-action-only (SAO) action, rare among micro-compact 9mm pistols which are overwhelmingly striker-fired; FN markets this as delivering a better trigger and an easier-to-rack slide. Capacity is 11+1 with the flush magazine or 15+1 with the extended magazine; a 10-round flush magazine is available for capacity-restricted states. The Reflex MRD variant is optics-ready with a milled slide. Width is just 1 inch at the slide. Trigger pull rated 4.5-5.5 lb (approximately 20-24 N).
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- FN Herstal
- Category
- Pistol
- Country
- United States
- Status
- In production
- Produced
- 2023
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 84 mm
- Overall length
- 157 mm
- Height
- 108 mm
- Width
- 25 mm
- Weight, empty
- 522 g
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Short recoil
- Firing mechanism
- Internal hammer
- Trigger
- Single action
- Trigger pull
- 22.0 N
- Capacity
- 11
- Magazine
- Detachable box
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Polymer
- Slide
- Stainless steel
- Barrel
- Stainless steel
- Finish
- Matte black
BallisticsFrom the service cartridge, not a handload.
- Muzzle velocity
- 340 m/s
- Muzzle energy
- 431 J
- Effective range
- 25 m
- Maximum range
- 1500 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
Internal hammer fired
Single action only
Micro compact
Slim 1 inch slide
Cold hammer forged barrel
Recessed target crown
Tritium front sight
3 dot iron sights
Reversible mag release
Flat faced trigger
Easy rack slide
Extended magazine option
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 560 9x19mm Parabellum pistols | 522 g | 765 g | Lighter than about 90% |
| Overall lengthAmong 559 9x19mm Parabellum pistols | 157 mm | 191 mm | Shorter than about 90% |
| Barrel lengthAmong 569 9x19mm Parabellum pistols | 84 mm | 105 mm | Shorter than about 90% |
| Magazine capacityAmong 571 9x19mm Parabellum pistols | 11 | 15 | Holds fewer rounds than about 80% |
Answers
Questions about the FN Reflex
How much does the FN Reflex weigh?
The FN Reflex weighs 522 g (1.15 lb) empty.
What caliber is the FN Reflex?
The FN Reflex is chambered in 9x19mm Parabellum.
How many rounds does the FN Reflex hold?
The FN Reflex holds 11 rounds, fed from a detachable box magazine.
How long is the FN Reflex?
The FN Reflex is 157 mm (6.18 in) long overall, with a 84 mm (3.31 in) barrel.
Who makes the FN Reflex?
The FN Reflex is made by FN Herstal (Belgium).
When was the FN Reflex introduced?
The FN Reflex was introduced in 2023.
How does the FN Reflex operate?
The FN Reflex uses a short recoil action, and its firing mechanism is internal hammer.
