PSA AK-47 GF3
- Category
- Rifle
- Barrel
- 406 mm
- Weight, empty
- 3.04 kg
- Introduced
- 2018
About
What it is, and why it matters
The PSA AK-47 GF3 (third-generation 'Gen3 Forged') is Palmetto State Armory's American-made AK-47 chambered in 7.62x39mm. Built on a 1mm stamped steel receiver with a hammer-forged front trunnion, hammer-forged bolt and carrier, and a nitrided 4150 steel barrel with a 1:9.5 twist and M14x1 LH muzzle threads, the GF3 was PSA's answer to the inconsistent quality of earlier domestic AK attempts. It uses a mil-spec single-hook trigger, an 800-yard rear sight leaf, and a side-rail optic mount, and ships in trims including Magpul MOE ('MOEkov') and Zhukov furniture as well as classic wood. Largely U.S.-made aside from a Korean-sourced trunnion and Israeli-sourced bolt finished by PSA, the GF3 helped legitimize PSA as a serious AK manufacturer and made an affordable, reliable stamped AK widely available to American buyers.
After several false starts with domestic AK production, Palmetto State Armory's GF3 ('third generation, forged') finally delivered a reliable, affordable American AK-47, and its 'MOEkov' Magpul-furnished trim became one of the most recognizable budget AKs on the US market.
PSA's flagship US-made stamped AK; the GF3 ('Gen3 Forged') uses hammer-forged trunnion, bolt, and carrier. 16" nitride barrel, 1:9.5 twist, M14x1 LH threads. Ships in MOE (MOEkov), Zhukov, and classic configurations; the AKP GF3 is the pistol variant. Trunnion sourced from Korea and bolt from Israel, finished by PSA; most other parts US-made. MSRP around $700-800.
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- Palmetto State Armory
- Category
- Rifle
- Country
- United States
- Status
- In production
- Produced
- 2018
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 406 mm
- Overall length
- 889 mm
- Sight radius
- 378 mm
- Weight, empty
- 3.04 kg
- Weight, loaded
- 3.85 kg
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Gas operated long stroke
- Firing mechanism
- Hammer fired
- Trigger
- Single stage
- Trigger pull
- 31.0 N
- Capacity
- 30
- Magazine
- Detachable box
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Stamped steel
- Barrel
- Nitride steel
- Stock
- Polymer
- Finish
- Nitride
BallisticsFrom the service cartridge, not a handload.
- Muzzle velocity
- 715 m/s
- Muzzle energy
- 2019 J
- Effective range
- 350 m
- Maximum range
- 1500 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
Hammer forged front trunnion
Hammer forged bolt
Stamped steel receiver
Side rail optic mount
Magpul moe furniture
Us made
800m rear sight
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 40 7.62x39mm rifles | 3.04 kg | 3.49 kg | Lighter than about 90% |
| Overall lengthAmong 40 7.62x39mm rifles | 889 mm | 933 mm | Shorter than about 80% |
| Barrel lengthAmong 40 7.62x39mm rifles | 406 mm | 415 mm | Shorter than about 90% |
| Magazine capacityAmong 40 7.62x39mm rifles | 30 | 30 | Holds more rounds than about 70% |
Its place in the rankings
Answers
Questions about the PSA AK-47 GF3
How much does the PSA AK-47 GF3 weigh?
The PSA AK-47 GF3 weighs 3.04 kg (6.70 lb) empty and 3.85 kg (8.49 lb) loaded. It is the 2nd lightest of 40 7.62x39mm rifles in the catalogue.
What caliber is the PSA AK-47 GF3?
The PSA AK-47 GF3 is chambered in 7.62x39mm.
How many rounds does the PSA AK-47 GF3 hold?
The PSA AK-47 GF3 holds 30 rounds, fed from a detachable box magazine.
How long is the PSA AK-47 GF3?
The PSA AK-47 GF3 is 889 mm (35.0 in) long overall, with a 406 mm (16.0 in) barrel.
Who makes the PSA AK-47 GF3?
The PSA AK-47 GF3 is made by Palmetto State Armory (United States). It was designed by Mikhail Kalashnikov.
When was the PSA AK-47 GF3 introduced?
The PSA AK-47 GF3 was introduced in 2018.
How does the PSA AK-47 GF3 operate?
The PSA AK-47 GF3 uses a gas operated long stroke action, and its firing mechanism is hammer fired.
