Winchester Model 770
- Category
- Rifle
- Barrel
- 559 mm
- Weight, empty
- 3.40 kg
- Introduced
- 1969
About
What it is, and why it matters
The Winchester Model 770 is a bolt-action sporting rifle produced from 1969 to 1971 as an economy version of the Winchester Model 70. To reduce cost, it omitted the hinged floorplate and forend tip, instead using the blind magazine of the Model 670 while retaining the Model 70's three-position safety and a walnut Monte Carlo stock. Chambered in popular hunting cartridges including .30-06 Springfield, it was offered with a 22-inch barrel and open sights.
Introduced at the same time as the redesigned 'push-feed' Model 70 of 1968-1971, the Model 770 sat at the bottom of Winchester's bolt-action lineup as a value-priced hunting rifle before being dropped after only three years.
Short-lived budget rifle in the Winchester bolt-action line; produced only from 1969 to 1971. Other chamberings offered included .22-250 Remington, .222 Remington, .243 Winchester, .270 Winchester, and .308 Winchester.
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- Winchester Repeating Arms Company
- Category
- Rifle
- Country
- United States
- Status
- Discontinued
- Produced
- 1969 to 1971
- Variant of
- Economy model
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 559 mm
- Overall length
- 1118 mm
- Weight, empty
- 3.40 kg
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Bolt action
- Firing mechanism
- Hammer fired
- Trigger
- Single action
- Capacity
- 5
- Magazine
- Fixed box
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Steel
- Barrel
- Steel
- Stock
- Walnut
- Finish
- Blued
BallisticsFrom the service cartridge, not a handload.
- Muzzle velocity
- 880 m/s
- Muzzle energy
- 4515 J
- Effective range
- 500 m
- Maximum range
- 1000 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
No load solved for this record yetThe flight path is computed from a cartridge and a bullet. This record has no ammunition filed against its chambering, so there is nothing to solve.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
Blind magazine
Monte carlo stock
Open sights
No hinged floorplate
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 75 .30-06 Springfield rifles | 3.40 kg | 3.40 kg | Heavier than about 60% |
| Overall lengthAmong 73 .30-06 Springfield rifles | 1118 mm | 1100 mm | Longer than about 70% |
| Barrel lengthAmong 75 .30-06 Springfield rifles | 559 mm | 584 mm | Shorter than about 80% |
| Magazine capacityAmong 78 .30-06 Springfield rifles | 5 | 4 | Holds more rounds than about 80% |
Answers
Questions about the Winchester Model 770
How much does the Winchester Model 770 weigh?
The Winchester Model 770 weighs 3.40 kg (7.50 lb) empty.
What caliber is the Winchester Model 770?
The Winchester Model 770 is chambered in .30-06 Springfield.
How many rounds does the Winchester Model 770 hold?
The Winchester Model 770 holds 5 rounds, fed from a fixed box magazine.
How long is the Winchester Model 770?
The Winchester Model 770 is 1118 mm (44.0 in) long overall, with a 559 mm (22.0 in) barrel.
Who makes the Winchester Model 770?
The Winchester Model 770 is made by Winchester Repeating Arms Company (United States).
When was the Winchester Model 770 introduced?
The Winchester Model 770 was introduced in 1969 and discontinued in 1971.
How does the Winchester Model 770 operate?
The Winchester Model 770 uses a bolt action, and its firing mechanism is hammer fired.
