Sako Quad
- Category
- Rifle
- Barrel
- 560 mm
- Weight, empty
- 3.20 kg
- Introduced
- 2005
About
What it is, and why it matters
The Sako Quad is a Finnish bolt-action rimfire rifle introduced in 2005 with a defining feature unique among production rimfires: a tool-change interchangeable-barrel system that allows the same receiver and stock to be re-chambered in seconds between four different rimfire cartridges - .22 Long Rifle, .22 Winchester Magnum Rimfire, .17 Hornady Magnum Rimfire, and .17 Mach 2. The user inserts a special tool, turns it three full rotations, tilts the barrel up to release the action, and slots in another barrel; point of impact is retained between swaps. Two magazine bodies are supplied (one for the shorter .22 LR / .17 Mach 2 case, one for the longer .22 WMR / .17 HMR), and either a wood or synthetic stock with a Monte Carlo cheekpiece is available. The Quad was discontinued circa 2017, replaced in the Sako rimfire lineup by the simpler single-caliber Finnfire II.
The Quad was the only mainstream production bolt-action rimfire ever sold with a true four-caliber switch-barrel system - one rifle, four cartridges, no gunsmith required. Sako engineered the breech and barrel-collar interface so precisely that point of impact was retained after a barrel swap, making it possible for a hunter to carry a single Quad receiver and switch between subsonic .22 LR for rabbits, .22 WMR for fox, .17 HMR for long-range varmints, and .17 Mach 2 for inexpensive plinking - all in the same morning.
Specifications shown are typical for the Heavy Barrel model with the .22 LR barrel installed (560 mm / 22"). Barrel is 6-groove, 1:9" twist on the .17 HMR barrel and 1:16" on .22 LR. Weight varies by stock/barrel combination from approximately 2.6 kg (Sporter wood) to 3.5 kg (Heavy Barrel synthetic). Replacement barrels were sold as accessories for users who initially bought the rifle in only one caliber.
Specification
Everything measured
IdentityWhat it is, who built it and when.
- Manufacturer
- Sako Ltd.
- Category
- Rifle
- Country
- Finland
- Status
- Out of production
- Produced
- 2005 to 2017
DimensionsAs issued, without a magazine or an optic.
- Barrel
- 560 mm
- Overall length
- 1025 mm
- Weight, empty
- 3.20 kg
ActionHow it cycles, what trips it, and what feeds it.
- Action
- Bolt action
- Firing mechanism
- Striker fired
- Trigger
- Single stage
- Trigger pull
- 13.0 N
- Capacity
- 5
- Magazine
- Detachable box
MaterialsEach swatch is the material itself, not a colour chosen to stand for it.
- Frame
- Steel
- Barrel
- Steel
- Stock
- Polymer
- Finish
- Blued
BallisticsFrom the service cartridge, not a handload.
- Muzzle velocity
- 330 m/s
- Muzzle energy
- 141 J
- Effective range
- 100 m
- Maximum range
- 200 m
Trajectory
What the round does downrange
Solved from the muzzle figures and the bullet. The dashed rule is the effective range on the record, and the crosses are the steps the solver returned.
No load solved for this record yetThe flight path is computed from a cartridge and a bullet. This record has no ammunition filed against its chambering, so there is nothing to solve.
Features
What it has
What the record lists as fitted, drawn from the catalogue.
Interchangeable barrel system
Four calibers in one rifle- Tool change in seconds no armorer required
- Point of impact retained after barrel swap
50 degree bolt throw
Single stage adjustable trigger
Monte carlo synthetic or wood stock- Two magazine types 22lr 17m2 and 22wmr 17hmr
Length of pull adjustable via recoil pad spacers
Open sights optional
Standing
How it compares
Each figure against the firearms of the same type and cartridge that record it, or of the same type where that cartridge has too few. Positions are read to the nearest tenth.
| Measurement | This firearm | Median | Position |
|---|---|---|---|
| Empty weightAmong 215 .22 Long Rifle rifles | 3.20 kg | 2.61 kg | Heavier than about 80% |
| Overall lengthAmong 207 .22 Long Rifle rifles | 1025 mm | 1016 mm | Longer than about 60% |
| Barrel lengthAmong 228 .22 Long Rifle rifles | 560 mm | 547 mm | Longer than about 60% |
| Magazine capacityAmong 231 .22 Long Rifle rifles | 5 | 6 | Holds fewer rounds than about 60% |
Answers
Questions about the Sako Quad
How much does the Sako Quad weigh?
The Sako Quad weighs 3.20 kg (7.05 lb) empty.
What caliber is the Sako Quad?
The Sako Quad is chambered in .22 Long Rifle, .17 Hornady Magnum Rimfire, .17 Hornady Mach 2, and .22 Winchester Magnum Rimfire.
How many rounds does the Sako Quad hold?
The Sako Quad holds 5 rounds, fed from a detachable box magazine.
How long is the Sako Quad?
The Sako Quad is 1025 mm (40.4 in) long overall, with a 560 mm (22.0 in) barrel.
Who makes the Sako Quad?
The Sako Quad is made by Sako Ltd. (Finland).
When was the Sako Quad introduced?
The Sako Quad was introduced in 2005 and discontinued in 2017.
How does the Sako Quad operate?
The Sako Quad uses a bolt action, and its firing mechanism is striker fired.
